AC-1201 | DIN-Rail EtherCAT Coupler for Modular I/O Expansion
2-port EtherCAT coupler with RJ45 In/Out, supports E-BUS-based iPAC I/O modules in compact DIN-rail control systems
Features
- Designed for DIN-rail mounted iPAC I/O systems
- Coupling of EtherCAT terminals to 100BASE-TX EtherCAT networks
- Dual RJ45 ports (In/Out) for EtherCAT system chaining
- Shielded Cat.5 or better Ethernet cable compatibility
- E-BUS connector for direct I/O module expansion
- Fast communication delay: approx. 1μs
- Up to 65535 EtherCAT terminals per network
- Wide input range: DC 24V ±15–20%
- Compact dimensions: 100 x 24 x 80 mm, only 90g
- Wide temperature tolerance: -20°C to 60°C
DIN-Rail Industrial IPC Controller I/O Product Information
| Technical Specifications | |
|---|---|
| System | |
| Task within EtherCAT system | Coupling of EtherCAT Terminals to 100BASE-TX EtherCAT networks |
| Data Transfer Medium | Ethernet/EtherCAT cable (min. Cat.5), shielded |
| Distance Between Stations | Max. 100m (100BASE-TX) |
| Number of EtherCAT Terminals | Up to 65535 |
| Protocol | EtherCAT |
| Delay | Approx. 1μs |
| Data Transfer Rates | 100 Mbit/s |
| Bus Interface | 2 x RJ45 |
| Power | |
| Voltage Input | DC 24V ±15%~±20% |
| Chassis | |
| Dimensions | 100mm (L) x 24mm (W) x 80mm (H) |
| Net Weight | 90g |
| Environment | |
| Operating Temperature | -20°C ~ 60°C (–4°F ~ 140°F) |
| Storage Temperature | -40°C ~ 80°C (–40°F ~ 176°F) |
| Relative Humidity | 5–95% (Non-condensing) |
| Operating Vibration | 5–500Hz, 1.5Grms (IEC60068-2-64) |
| Operating Shock | 20G peak acceleration (1ms duration) (IEC60068-2-27) |
| EMC | CE / FCC Class A |
Click the link below to download datasheets or drivers:
Datasheet Downloads| Ordering Information | ||
|---|---|---|
| Model | CPU | Description |
| AC-1201 | — | EtherCAT Coupler Module with 2 x RJ45 (EtherCAT In/Out), connects iPAC I/O modules to EtherCAT network via E-BUS expansion |
