| Technical Specifications |
|---|
| Model Name | ABOX-6162-IO |
| CPU |
|---|
| Processor | Rockchip RK3399, Dual-core Cortex-A72 + Quad-core Cortex-A53, up to 1.8GHz |
| GPU | Mali-T860 MP4 quad-core GPU |
| Memory |
|---|
| RAM | Onboard LPDDR4 4GB |
| Storage |
|---|
| eMMC | Onboard 16GB eMMC |
| TF Card | 1 x TF card slot, supports storage expansion |
| I/O Interfaces |
|---|
| Ethernet | 3 x RJ-45 (2 x 10/100/1000Mbps, 1 x 10/100Mbps) |
| USB | 2 x USB2.0 |
| OTG | 1 x Micro USB OTG |
| Serial Ports | 2 x RS485, 2 x RS232 |
| Digital I/O | 16 x DI (NPN/PNP), 16 x DO (NPN) |
| CAN | 2 x CAN 2.0 A/B |
| SIM Slot | 1 x Micro SIM card slot |
| LED Indicators | Power (blue), Run (green), Alarm (yellow), Error (red) |
| Display | 1 x HDMI output (supports up to 4K @ 3840×2160) |
| Switch | Mode selector: Run / Stop |
| Expansion Slot | 1 x M.2 slot (supports optional LTE 4G module) |
| Operating System |
|---|
| Linux | Debian 10, Ubuntu 20.04 |
| Power |
|---|
| Input Voltage | DC 9-36V ±10%, with overcurrent, overvoltage, and reverse polarity protection |
| Power Consumption | ≤ 20W |
| Chassis |
|---|
| Structure | Aluminum-magnesium alloy box, fanless, wall-mounted or DIN-Rail mount supported |
| Dimensions | 150 mm (L) × 105 mm (W) × 36 mm (H) |
| Weight | 1.5 kg |
| Environmental |
|---|
| Operating Temperature | -20°C to 60°C |
| Storage Temperature | -40°C to 80°C |
| Relative Humidity | 5-95% @40°C, non-condensing |
| Vibration | 1.5Grms, 5~500Hz, 1 hr/axis (with SSD), IEC 60068-2-64 |
| Shock | 20G peak acceleration, 11ms (with SSD), IEC 60068-2-27 |
| EMC | CE/FCC Class A |
