NK-6180 | 3.5" Intel N97 / i3-N305 Industrial SBC with PCIe 4.0 NVMe, HDMI, DP, Dual LAN
Compact high-speed SBC with DDR5 memory, 4K triple display output, advanced I/O, PCIe 4.0 storage, and wide 12~24V DC input for industrial computing
Features
- Intel® Alder Lake-N platform: Celeron N97 or Core™ i3-N305
- DDR5-4800 SO-DIMM, up to 16GB
- 1 x M.2 2242/2280 M-Key (PCIe 4.0 x2) for NVMe SSD
- 2 x 2.5G LAN (Intel® i225/i226-V)
- HDMI, DisplayPort, LVDS/eDP triple display (up to 4K)
- 6 x COM, 4 x USB (2 x USB 3.2 Gen2, 2 x USB 2.0)
- 1 x Mini PCIe with Nano-SIM (for 4G/5G/Wi-Fi module)
- 12–24V DC input, Phoenix connector
- TPM 2.0 support (fTPM)
Embedded Industrial SBC Motherboard Product Information
| Technical Specifications | |
|---|---|
| System | |
| CPU | Intel(r) CoreTM i3-N305 / Intel(r) N97 processor (Alder Lake-N), Quad-core, up to 3.8GHz, TDP 12~15W |
| Chipset | Intel(r) SoC integrated |
| BIOS | AMI 256Mb UEFI BIOS |
| Memory | |
| Type | DDR5-4800MHz, Single Channel, Non-ECC |
| Slot | 1 x DDR5 262-pin SO-DIMM, up to 16GB |
| Storage | |
| M.2 | 1 x M.2 2242/2280 M-Key SSD slot (PCIe 4.0) |
| Graphics | |
| Controller | Intel(r) UHD Graphics integrated |
| External Display | 1 x DP 1.4 (4096×2160@60Hz), 1 x HDMI (4096×2160@30Hz) |
| Internal Display | 1 x LVDS (1920×1200@60Hz), 1 x eDP 1.3 (4096×2160@60Hz, shared with LVDS) |
| Audio | |
| Codec | Realtek ALC897 |
| Rear I/O | |
| Ethernet | 2 x GbE LAN (Intel(r) i225-V / i226-V) |
| USB | 2 x USB 3.2 Gen2 (10Gbps), 2 x USB 2.0 |
| Button | 1 x Power Button (White = ON, Blink = Sleep, Off = OFF) |
| Indicators | 1 x SATA LED (Red), 1 x Power LED (Green) |
| Internal I/O | |
| USB | 2 x USB 2.0 wafer (1×4pin) |
| COM Ports | 1 x RS232/485, 1 x RS232, 4 x TTL (2×4pin wafer) |
| Audio | 1 x Mic-in/Line-out wafer (2×5pin) |
| Fan | 1 x Smart Fan wafer (1×4pin) |
| GPIO | 1 x 8-bit GPIO (2×5pin) |
| SMBus | 1 x SMBus wafer (1×4pin) |
| eSPI | 1 x eSPI header for debug |
| Front Panel | 1 x Power LED, HDD LED, Power Button, Reset Button (wafer) |
| Expansion | |
| Mini PCIe | 1 x Mini PCIe slot with Nano-SIM socket (PCIe/USB2.0) |
| Security | |
| TPM | Supports fTPM 2.0 |
| Watchdog Timer | |
| Interval | 1-255 seconds, system reset |
| Power | |
| Input | 12~24V DC input ±10% |
| Connector | 2-pin Phoenix terminal block |
| Power Consumption | TBD |
| OS Support | |
| Windows | Windows 10 / 11 |
| Linux | Supported |
| Mechanical | |
| Dimensions | 146mm (L) × 102mm (W) |
| Weight | 0.8 kg |
| Environment | |
| Operating Temperature | -10°C ~ 60°C (with SSD) |
| Storage Temperature | -40°C ~ 85°C |
| Humidity | 5-95% RH (non-condensing) |
| Vibration | 5-500Hz, 3Grms operating (IEC60068-2-64) |
| Ordering Information | |||
|---|---|---|---|
| Part No. | Model | CPU | Description |
| F32.618003.10.NEK | NK-6180 | Intel(r) N97 | 3.5" embedded board with Intel N97, DDR5 SO-DIMM, M.2 (PCIe 4.0), 2 GbE LAN, HDMI + DP + eDP/LVDS, 6 COM, 4 USB, Mini PCIe, 12-24V DC input |
| F32.618103.10.NEK | NK-6180 | Intel(r) CoreTM i3-N305 | 3.5" embedded board with Intel i3-N305, DDR5 SO-DIMM, M.2 (PCIe 4.0), 2 GbE LAN, HDMI + DP + eDP/LVDS, 6 COM, 4 USB, Mini PCIe, 12-24V DC input |
| Packing List | ||
|---|---|---|
| Part No. | Qty | Description |
| KF0.001046.00.L54 | 2 | COM cable, 2x5pin wafer to DB9, 150mm |
| KF0.001049.00.L54 | 1 | SATA power + signal cable |
| JF7.000041.00.D03 | 1 | 2-pin Phoenix terminal block (5.08mm pitch) |
| Optional Accessories | ||
|---|---|---|
| Part No. | Description | Notes |
| C2Z.612001.0A.NDJ | NK-6180 Heatsink | Passive aluminum heatsink |
| C3Z.NKEB01.10.NDJ | AEB-4COM00 Expansion Module | 2 x RS485/422/232 DB9, 2 x RS232 wafer |
| C3Z.0001.00.NDJ | 12V/60W Adapter | CM-060W-CWT0, 180cm cable |
| C3Z.0002.00.NDJ | 12V/84W Adapter | CM-090W-HKA, 180cm cable |
| KF0.001047.00.L54 | USB Cable | 1x4pin wafer to USB2.0 Type-A, 150mm |
| KF0.001048.00.L54 | USB Y Cable | 2 x USB2.0 Type-A Y cable with bracket, 150mm |
| KF0.000949.00.Y09 | Audio Cable | 2x5pin wafer to Mic-in/Line-out, 300mm |
