| Technical Specifications |
| System |
| CPU |
Intel(r) Celeron(r) J6412, Dual-core, 2.0GHz (up to 2.6GHz), TDP 10W |
| Chipset |
Intel(r) SoC integrated |
| BIOS |
AMI 128Mb UEFI BIOS |
| Memory |
| Type |
Single-channel DDR4-3200MHz, Non-ECC |
| Slot |
1 x DDR4 260-pin SO-DIMM, up to 32GB |
| Graphics |
| Controller |
Intel(r) HD Graphics integrated |
| Display |
2 x DDI, 1 x eDP (triple display supported) |
| Expansion & I/O Interfaces |
| USB |
2 x USB 3.0, 8 x USB 2.0 |
| SATA |
2 x SATA 3.0 ports |
| Serial Ports |
2 x UART (9-line), 4 x UART (3-line) |
| PCIe |
5 lanes total (1 x2, 3 x1) |
| GPIO |
1 x 4-bit GPIO |
| Audio |
Intel HDA Audio codec |
| Smart Fan |
1 x Smart Fan interface |
| LAN |
Intel(r) i210AT Controller (via carrier board) |
| Other I/O |
1 x eSPI, 1 x I²C, 1 x SMBus, 1 x Buzzer, 1 x KB/MS |
| Watchdog Timer |
| Output & Interval |
System reset, programmable from 1 to 255 seconds |
| Power |
| Input |
5V DC (via carrier board) |
| OS Support |
| Windows |
Windows 10 / 11 |
| Linux |
Supported |
| Mechanical |
| Dimensions |
95mm (L) × 82mm (W) |
| Weight |
0.04 kg |
| Environment |
| Operating Temperature |
0°C ~ 60°C (with SSD) |
| Storage Temperature |
-40°C ~ 85°C |
| Humidity |
5-95% RH (non-condensing) |
| Vibration |
5-500Hz, 3Grms (IEC60068-2-64) |
