| Technical Specifications |
| System |
| CPU |
Intel(r) 6th/7th/8th/9th Gen Celeron/Pentium/CoreTM-i Series, LGA1151, TDP up to 65W |
| Chipset |
Intel(r) SoC integrated (H110) |
| BIOS |
AMI 128Mb UEFI BIOS |
| Memory |
| Technology |
Dual Channel DDR4-1866/2133/2400/2666MHz, Non-ECC |
| Slot |
2 x DDR4 260-pin SO-DIMM, up to 64GB |
| Graphics |
| Controller |
Intel(r) HD Graphics integrated |
| Display Outputs |
2 x DDI, 1 x eDP (Triple display supported) |
| I/O Interfaces |
| USB |
4 x USB 3.0, 8 x USB 2.0 |
| Serial Ports |
2 x UART (5-wire), 4 x UART (3-wire) |
| SATA |
2 x SATA 3.0 |
| PCIe |
7 lanes total: 1 x4, 2 x1, 1 x GbE (Intel i219-V only) |
| PCIe x16 |
1 x PCIe x16 slot |
| GPIO |
1 x 2-bit GPIO |
| Audio |
1 x Intel HDA Audio Codec |
| Fan |
1 x Smart Fan header |
| Other Interfaces |
1 x I²C, 1 x SMBus, 1 x LPC, 1 x Buzzer |
| Watchdog Timer |
| Output & Interval |
System reset, programmable from 1 to 255 seconds |
| Power |
| Input |
12V DC |
| OS Support |
| Microsoft Windows |
Windows 7 (only with 6th Gen CPU), Windows 10/11 |
| Linux |
Supported |
| Mechanical |
| Dimensions |
138mm (L) x 100.1mm (W) |
| Weight |
0.15 kg |
| Environment |
| Operating Temperature |
0°C ~ 60°C (with SSD) |
| Storage Temperature |
-40°C ~ 85°C |
| Humidity |
5-95% RH (non-condensing) |
| Vibration |
5-500Hz, 3Grms operating (IEC60068-2-64) |
