| Technical Specifications -- SmartLinc6-V156 |
|---|
| System |
|---|
| CPU | Intel(r) Processor N97 / Intel(r) CoreTM i5-7200U, i7-7500U, i3-1215U, i5-1235U, i7-1255U |
| Memory | 1 × DDR4-3200 SO-DIMM, up to 32GB |
| Storage | 1 × M.2 2242/2280 M-Key SSD slot (SATA 3.0 / NVMe) |
| USB | 4 × USB 3.0 |
| Camera | 1 × 1080P dynamic sensor (Optional) |
| NFC | Supports NFC, 13.56 MHz |
| COM | 2 × RS-232 (RS-485 optional) |
| LAN | 2 × GbE (RJ45), Realtek 8111 controller |
| Expansion Slot | 1 × Mini-PCIe slot, expandable 4G / Wi-Fi |
| OS Support | Windows 10, Linux |
| LCD & Touch |
|---|
| LCD Size | 15.6" FHD TFT LCD |
| Resolution | 1920 × 1080 |
| Luminance | 250 cd/m² |
| Contrast Ratio | 800 : 1 |
| Touch Type | Multipoint capacitive touch |
| Transmittance | ≥ 87% |
| Controller Interface | USB 2.0 |
| Power |
|---|
| Input Voltage | DC 12V (N97 / 7200U / 7500U CPU); DC 12V~7A (12th Gen CPU) |
| Chassis |
|---|
| Structure | Ultra-compact, fanless design; front panel IP65 compliant |
| Dimensions (W × H × D) | 406.5 mm × 265 mm × 60 mm |
| Net Weight | 4.59 kg |
| VESA | 100 mm × 100 mm |
| Environmental |
|---|
| Operating Temperature | 0 ~ 50 °C |
| Storage Temperature | -20 ~ 60 °C |
| Relative Humidity | 5-95% @ 40 °C (non-condensing) |
| Vibration | SSD applied: 1.5 Grms, IEC 60068-2-64, random, 5-500 Hz, 1 hr/axis |
| Shock | SSD applied: 10G, IEC 60068-2-27, half-sine wave, 11 ms |
| EMC | -- |
| Ordering Information -- SmartLinc6-V156 |
|---|
| Model Name | Description |
| SmartLinc6-V156 | 15.6" FHD TFT LCD (1920×1080), multipoint capacitive touch; Intel Processor N97 / Intel CoreTM i5-7200U, i7-7500U, i3-1215U, i5-1235U, i7-1255U; 1× DDR4-3200 SO-DIMM up to 32GB; 1× M.2 2242/2280 M-Key SSD slot (SATA 3.0/NVMe); 2× GbE (RJ45, Realtek 8111); 4× USB3.0; 2× RS-232 (RS-485 optional); built-in NFC 13.56 MHz; optional 1080P camera; DC 12V input; fanless, front IP65; panel/VESA mount (100×100). |
| Options |
|---|
| Camera | 1080P dynamic sensor (optional) |
| Wireless/Cellular | Mini-PCIe expansion for 4G / Wi-Fi |
| Memory | DDR4-3200 SO-DIMM, up to 32GB |
| Storage | M.2 2242/2280 SSD (SATA 3.0 or NVMe), capacities per configuration |
| OS | Windows 10, Linux |
| Note | Optional parts may require additional regional compatibility certifications; contact NODKA for details. |
