| Technical Specifications -- SmartLinc6-V215 |
| System |
| CPU |
Intel(r) Processor N97 / Intel(r) CoreTM i5-7200U, i7-7500U, i3-1215U, i5-1235U, i7-1255U |
| Memory |
1 × DDR4-3200 SO-DIMM, up to 32 GB |
| Storage |
1 × M.2 2242 / 2280 M-Key SSD slot (SATA 3.0 / NVMe) |
| USB |
4 × USB 3.0 |
| Camera |
1 × 1080 P dynamic sensor (optional) |
| NFC |
Supports NFC, 13.56 MHz |
| COM |
2 × RS-232 (RS-485 optional) |
| LAN |
2 × GbE (RJ-45, Realtek 8111 controller) |
| Expansion Slot |
1 × Mini-PCIe slot (expandable 4G / Wi-Fi) |
| OS Support |
Windows 10, Linux |
| LCD & Touch |
| LCD Size |
21.5" FHD TFT LCD |
| Resolution |
1920 × 1080 |
| Luminance |
250 cd/m² |
| Contrast Ratio |
1000 : 1 |
| Touch Type |
Multipoint capacitive touch |
| Transmittance |
≥ 87 % |
| Controller Interface |
USB 2.0 |
| Power |
| Input Voltage |
DC 12 V (N97 / 7200 U / 7500 U); DC 12 V ~ 7 A (12th Gen CPU) |
| Chassis |
| Structure |
Ultra-compact fanless design; front panel IP65 compliant |
| Dimensions (W × H × D) |
545.5 mm × 340 mm × 60 mm |
| Net Weight |
6.85 kg |
| VESA |
100 mm × 100 mm |
| Environmental |
| Operating Temperature |
0 ~ 50 °C |
| Storage Temperature |
-20 ~ 60 °C |
| Relative Humidity |
5 ~ 95 % @ 40 °C (non-condensing) |
| Vibration |
SSD applied: 1.5 Grms, IEC 60068-2-64, 5-500 Hz, 1 hr/axis |
| Shock |
SSD applied: 10 G, IEC 60068-2-27, half-sine, 11 ms |
| Ordering Information -- SmartLinc6-V215 |
|---|
| Model Name | Description |
| SmartLinc6-V215 | 21.5" FHD TFT LCD (1920×1080), multipoint capacitive touch, Intel Processor N97 / Core i3/i5/i7; 1× DDR4 SO-DIMM up to 32 GB; 1× M.2 2242/2280 SSD (SATA 3.0 / NVMe); 2× GbE; 2× RS-232 (RS-485 opt.); 4× USB 3.0; NFC 13.56 MHz; optional 1080 P camera; DC 12 V input; fanless IP65 front; panel / VESA mount (100×100). |
| Options |
|---|
| Camera | 1080 P dynamic sensor (optional) |
| Wireless / Cellular | Mini-PCIe expansion for 4 G / Wi-Fi |
| Memory | DDR4-3200 SO-DIMM up to 32 GB |
| Storage | M.2 2242/2280 SSD (SATA 3.0 / NVMe) |
| OS | Windows 10, Linux |
