PANEL5000-D1562-LH | 15.6” Resistive Touch Industrial Monitor with IP65 Front Panel
15.6″ industrial resistive touch monitor with VGA & DVI-D input, wide voltage support, and multiple mounting options
Features
- 15.6” TFT LCD (1366×768 or 1920×1080) with 400 cd/m² or 250 cd/m² brightness
- Resistive touch screen for industrial environments
- Durable aluminum-magnesium alloy front panel with IP65 protection
- Multiple mounting options (Panel mounted, Wall-mounted, Desktop, VESA 75×75 & 100×100)
- VGA & DVI-D signal input for high compatibility
- Wide voltage input (DC12-24V) for flexible power options
- Long lifespan LED backlight with MTBF of 50,000 hours
Resistive Touch Industrial Monitor Product Information
| Technical Specifications | ||||
|---|---|---|---|---|
| Model Name | PANEL5000-D1562-LH | |||
| General | ||||
| Control Button | Set Contrast Ratio and Luminance via OSD at the back panel | |||
| Dimensions (W x H x D) | 405mm × 258mm × 47mm | |||
| Cut-out Size (W x H) | 387mm × 240mm | |||
| Box Structure | Front panel: aluminum-magnesium alloy, anodized coating; Back cover: SGCC, Ground isolation protection | |||
| Mounting Support | Panel mounted, Wall-mounted, Desktop (VESA 75x75 & 100x100) | |||
| Power Supply | DC 12-24V | |||
| Power Dissipation | 12W | |||
| Signal Input | VGA & DVI-D | |||
| Net Weight | 3.8kg | |||
| LCD | ||||
| LCD Size | 15.6" TFT | |||
| Resolution | 1366 x 768 / 1920 x 1080 | |||
| Colors | 16.7M | |||
| Active Area (W x H) | 344.232mm × 193.536mm / 344.16mm × 193.59mm | |||
| Backlight | LED | |||
| MTBF | 50,000 hours / 15,000 hours | |||
| Brightness | 400 cd/m² / 250 cd/m² | |||
| Contrast Ratio | 800:1 / 3000:1 | |||
| Viewing Angle | (L) 85 / (R) 85 / (T) 50 / (B) 80 / (L) 89 / (R) 89 / (T) 89 / (B) 89 | |||
| Touchscreen | ||||
| Type | Resistive Touch Screen | |||
| Resolution | 4096 x 4096 | |||
| Transmittance | > 75% | |||
| Controller Interface | USB / RS-232C | |||
| Driver Support | Windows XP, Windows 7, Windows 8, Windows 10, Linux | |||
| Response Time | < 5ms | |||
| Surface Hardness | Mohs' 3H | |||
| Environmental | ||||
| Operating Temperature | -20 ~ 60°C (-4 ~ 140 ℉) / 0 ~ 45°C (32 ~ 113 ℉) | |||
| Storage Temperature | -30 ~ 80°C (-22 ~ 176 ℉) | |||
| Relative Humidity | 5~95% RH@40°C, non-condensing | |||
| Vibration Resistance | 5~500Hz, 1.5Grms, IEC 60068-2-64 | |||
| Shock Resistance | 10G peak acceleration (11ms duration), IEC 60068-2-27 | |||
| EMC | CE/FCC Class B | |||
| Waterproof Rating | IP65 Compliant (Front Panel) | |||
Click the link below to download datasheets or drivers:
| Ordering Information | ||
|---|---|---|
| Model Name | Description | |
| PANEL5000-D1562-LH | 15.6" Resistive Touchscreen Monitor, 1366×768 or 1920×1080 resolution, Resistive touch screen, VGA & DVI-D input, Wide voltage input (DC12-24V), IP65 front panel, Multiple mounting options (Panel mounted, Wall-mounted, Desktop, VESA 75x75 & 100x100). | |
| Options | ||
|---|---|---|
| Display Size | 15.6" TFT LCD | |
| Resolution | 1366 × 768 / 1920 × 1080 | |
| Touch Technology | Resistive Touch Screen | |
| Signal Input | VGA & DVI-D | |
| Mounting Options | Panel mounted, Wall-mounted, Desktop, VESA 75x75 & 100x100 | |
| Power Input | DC 12-24V | |
| Brightness | 400 cd/m² / 250 cd/m² | |
| Contrast Ratio | 800:1 / 3000:1 | |
| Waterproof Rating | IP65 (Front Panel) | |
| Operating Temperature | -20 ~ 60°C (-4 ~ 140 ℉) / 0 ~ 45°C (32 ~ 113 ℉) | |
| Included Accessories | VGA Cable (1.8M), USB Cable (1.8M), Adapter (12V/3.33A, 40W 2-pin Phoenix terminal) | |
| Optional Accessories | VGA Cable (3M / 5M) USB Cable (3M / 5M) DVI-D Cable (1.8M / 3M / 5M) Power Cord (1.8M / 3M / 5M) |
|
