AIPC-3000-AQ6-6L | High Performance Tower / Wallmount Industrial PC
High-power tower/wallmount industrial PC supporting Intel® 12th–14th Gen CPUs (up to 65W) with Q670 chipset, dual Intel GbE, 4×RS-232, 4×USB 3.0, VGA+DVI dual display, 2×PCIe x16 (default x8 link) + 1×PCIe x4 expansion for GPU/AI cards up to 300mm, NVMe + SATA storage, and 750W wide-range AC power supply
Features
- Supports Intel® 12th/13th/14th Gen Celeron/Pentium/Core-i processors (up to 65W TDP)
- Intel® Q670 chipset platform for high-performance industrial computing
- High-power expansion: 2 × PCIe x16 (default 2 × x8 link) + 1 × PCIe x4 for GPU / AI accelerator cards (up to 300mm)
- Dual Intel GbE LAN for industrial networking and network segmentation
- 4 × RS-232 serial ports for PLCs, instruments, and legacy device connectivity
- Storage support: 1 × M.2 2242/2280 NVMe + 2 × SATA (3.5″ + 2.5″)
- Wireless-ready: Mini PCIe for WiFi/4G modules and M.2 Key-B for 5G modules
- VGA + DVI dual display up to 1920 × 1200 @ 60Hz (asynchronous)
- Wide-range AC 90–264V input with 750W power supply for high-wattage GPU workloads
- Watchdog timer with 1–255 programmable levels
- All-steel chassis for tower or wallmount control cabinet installation
Tower / wall mount Industrial PC Product Information
| Technical Specifications -- AIPC-3000-AQ6-6L | |
|---|---|
| Model Name | AIPC-3000-AQ6-6L |
| System | |
| CPU | Intel® 12/13/14th Generation Celeron/Pentium/Core-i series processor, TDP up to 65W |
| BIOS | AMI UEFI 128Mbit |
| Chipset | Intel® Q670 Chipset |
| Memory | 2 × SO-DIMM slots, up to 64GB |
| Storage | 1 × M.2-2242/2280 Key M slot NVMe 2 × SATA (3.5" + 2.5") |
| USB | 4 × USB3.0 |
| COM | 4 × RS-232 (COM1–4) |
| Expansion Slot | 2 × PCIe x16 (default 2 × x8 link) + 1 × PCIe x4 (expandable graphics cards up to 300mm in length) 1 × Mini PCIe, expandable WiFi and 4G module 1 × M.2 Key-B slot, expandable 5G module |
| LAN | 2 × Intel GbE LAN |
| DVI | The highest resolution is 1920 × 1200 @ 60Hz, supports asynchronous dual display |
| VGA | The highest resolution is 1920 × 1200 @ 60Hz, supports asynchronous dual display |
| Watchdog | 1–255 levels programmable setting |
| OS Support | |
| Microsoft Windows | Windows 10, Windows 11 |
| Linux | Linux |
| Power | |
| Input Voltage | AC 90~264V |
| Power Consumption | 750W |
| Output Voltage | DC12V |
| Chassis | |
| Structure | All-steel box structure |
| Dimensions (L × W × H) | 370mm × 252.5mm × 234.8mm |
| Net Weight | 10Kg |
| Environment | |
| Operating Temperature | 0°C ~ 35°C (Use SSD) |
| Storage Temperature | -40°C ~ 80°C (Use SSD) |
| Relative Humidity | 5~95% RH @ 40°C, non-condensing |
| Vibration | SSD applied: 1.5Grms, IEC 60068-2-64, random, 5~500Hz, 1 hr/axis |
| Shock | SSD applied: 10G, IEC 60068-2-27, half sine wave, lasting 11ms |
| EMC | CE/FCC Class A |
| Ordering Information -- AIPC-3000-AQ6-6L | |
|---|---|
| Part Number | A63.AIPCQ.6L.0001 |
| Model Name | AIPC-3000-AQ6-6L |
| Description | Barebones: Q670 chipset / 2 × PCIe16X + 1 × PCIe4X / 4 × COM / 2 × LAN / 4 × USB3.0 / AC220V input |
| Options | |
| DDR4 SO-DIMM | 4GB, 8GB, 16GB, 32GB |
| M.2 SATA | 128GB, 256GB, 512GB, 1TB |
| 2.5" Solid State Drives | 128GB, 256GB, 512GB, 1TB |
| 3.5" Hard Drive | 1TB, 2TB, 4TB |
