NP-6116-IO-J6412 | Compact Fanless DIN Rail Automation PC with DI/DO & Dual Display
Industrial fanless PC with Intel J6412 CPU, 3 LAN, HDMI + DP, 8 x DI/DO, and Mini PCIe with SIM, designed for DIN rail or wall mounting
Features
- Fanless DIN-rail or wall-mounted embedded automation PC
- Intel® Celeron J6412 processor with 4 cores and low 10W TDP
- 3 x Intel® Gigabit LAN, 3 x USB 3.1, 1 x RS232 + 1 x RS485
- 1 x HDMI and 1 x DisplayPort, supporting up to 4K resolution
- 8 x DI / 8 x DO (NPN or PNP options for digital I/O control)
- Full-size Mini PCIe with SIM slot for wireless module expansion
- 1 x M.2 2242 slot for high-speed SSD storage
- 12–24V DC input with protection for overvoltage, current, and polarity
- Rugged aluminum-magnesium housing with passive cooling
- Operating temperature: -20°C to 60°C
Fanless Control Cabinet Industrial PCs Product Information
| Technical Specifications | |
|---|---|
| System | |
| CPU | Intel(r) Celeron J6412, 2.0~2.6GHz, 4 cores/4 threads, 1.5MB L2 cache |
| TDP | 10W |
| BIOS | AMI UEFI, 256Mb |
| Memory | 1 x SO-DIMM DDR4-3200MHz (up to 32 GB) |
| Storage | 1 x M.2 2242 |
| I/O Interfaces | |
| USB | 3 x USB 3.1 |
| COM | 1 x RS232, 1 x RS485 |
| Ethernet | 3 x Intel(r) Gigabit LAN |
| Display | 1 x HDMI (up to 3840 x 2160 @60Hz), 1 x DP (up to 4096 x 2160 @60Hz) |
| DIO | 8 x DI, 8 x DO (NPN or PNP model dependent) |
| LED | 1 x LED |
| Expansion | |
| Mini PCIe | 1 x Full-size Mini PCIe slot with SIM card holder |
| Watchdog Timer | 1~255 level programmable |
| Power | |
| Input Voltage | DC 12~24V ±10%, with over-current, over-voltage, and polarity inverse protection |
| Power Consumption | Max. 60W |
| Mechanical | |
| Structure | Fanless embedded cooling, Wall-mounted or DIN-Rail fixing style |
| Dimensions | 178mm (L) x 102mm (W) x 48mm (H) |
| Net Weight | 1.15 Kg |
| Environmental | |
| Operating Temperature | -20°C ~ 60°C |
| Storage Temperature | -40°C ~ 80°C |
| Humidity | 5~95% RH (Non-condensing) |
| Vibration | 1.5Grms (5~500Hz, with SSD), IEC60068-2-64 compliant |
| Shock | 20G peak acceleration (11ms), IEC60068-2-27 compliant |
| EMC | CE/FCC Class B |
| OS Support | |
| Microsoft Windows | Windows 10 |
| Linux | Ubuntu |
Click the link below to download datasheets or drivers:
| Ordering Information | ||
|---|---|---|
| Model | CPU | Description |
| NP-6116-IO-N-J6412 | Intel(r) Celeron J6412 | Fanless automation PC with 3 x LAN, 3 x USB3.1, 1 x RS232, 1 x RS485, 8 x DI, 8 x DO (NPN), HDMI + DP display, Mini PCIe with SIM, 12-24V DC input, DIN/wall mount |
| NP-6116-IO-P-J6412 | Intel(r) Celeron J6412 | Fanless automation PC with 3 x LAN, 3 x USB3.1, 1 x RS232, 1 x RS485, 8 x DI, 8 x DO (PNP), HDMI + DP display, Mini PCIe with SIM, 12-24V DC input, DIN/wall mount |
| Optional Items | |
|---|---|
| Memory | 4GB / 8GB DDR3L SO-DIMM |
| Storage | M.2 SATA SSD: 128GB / 256GB / 512GB / 1TB / 2TB |
| Wireless Module | Mini PCIe Wi-Fi (7260 series) / 3G/4G module (EC20, EG25, EC25) with SIM slot support |
| Mounting Kit | Wall-mount and DIN rail brackets (included) |
