| Technical Specifications |
| System |
| Model |
IPC-615G2-Q470 |
| CPU |
Intel® 10th Gen Core / Pentium / Celeron Desktop CPU (LGA1200) |
| Max CPU TDP |
Up to 125W (Deca-Core) |
| Chipset |
Intel® Q470 |
| Memory |
4 x DDR4-2400/2666/2933MHz Non-ECC U-DIMM, up to 128GB |
| Display |
| VGA |
1920 x 1200 @ 60Hz |
| DVI-D |
1920 x 1200 @ 60Hz |
| HDMI |
4096 x 2160 @ 30Hz |
| I/O Interfaces |
| COM |
3 x RS232, 1 x RS232 or RS485, 1 x RS232/RS485/422 |
| USB |
4 x USB 3.0, 4 x USB 2.0 |
| LAN |
2 x Intel Gigabit LAN (I219 & I211) |
| Audio |
Realtek ALC662, 5.1 channel HD audio (2 x MIC, 2 x Line-out, 1 x Line-in) |
| PS/2 |
1 x PS/2 for keyboard/mouse |
| Expansion |
| Mini PCIe |
1 x Mini PCIe (full-size) with SIM card slot |
| PCIe |
1 x PCIe x16, 1 x PCIe x16 (x8 signal), 3 x PCIe x4 |
| PCI |
2 x PCI (32-bit) |
| Storage |
| M.2 |
1 x M.2 Key-M (2242/2280), PCIe x4 NVMe / SATA Auto Detect |
| SATA |
4 x SATA 3.0 (7-pin) |
| RAID |
Supports RAID 0, 1, 5, 10 |
| OS Support |
| Microsoft Windows |
Windows 10 64-bit |
| Linux |
Ubuntu |
| Power |
| Power Type |
ATX |
| Input Voltage |
AC 180–264V |
| Power Supply Options |
Built-in: 300W (default), Optional: 500W, 750W |
| Power Dissipation |
Depends on CPU configuration |
| Mechanical |
| Structure |
Hot-dip galvanized steel shell |
| Mounting |
Standard rack-mount IPC |
| Dimensions |
370mm x 326.2mm x 187.2mm |
| Environmental |
| Operating Temperature |
0°C ~ 45°C |
| Storage Temperature |
-40°C ~ 80°C |
| Humidity |
5–95% RH (non-condensing) |
| Vibration |
1.5 Grms, 5–500Hz, IEC 60068-2-64 |
| Shock |
10G peak, 11ms, IEC 60068-2-27 |
| Certification |
CCC |
| Ordering Information |
| Model |
Power Supply |
Description |
| IPC-615G2-Q470-P300 |
300W ATX |
Rackmount IPC with Intel Q470 chipset, supports 10th Gen LGA1200 CPUs, 2 x PCI, 5 x PCIe, dual LAN, audio, HDMI/DVI/VGA, RAID, M.2, 4 x SATA, 6 COM, 8 USB |
| IPC-615G2-Q470-P500 |
500W ATX |
Same as above with higher power capacity for GPU or high-load expansion cards |
| IPC-615G2-Q470-P750 |
750W ATX |
Same as above with maximum power configuration for full expansion and AI cards |
| Optional Items |
| CPU Support |
Intel® 10th Gen Core / Pentium / Celeron Desktop CPU (LGA1200) |
| Memory |
4GB / 8GB / 16GB / 32GB / 64GB / 128GB DDR4 U-DIMM |
| Storage |
4 x SATA HDD/SSD, M.2 NVMe SSD (2242/2280) |
| Expansion |
1 x PCIe x16, 1 x PCIe x16 (x8 signal), 3 x PCIe x4, 2 x PCI |
| RAID Support |
RAID 0, 1, 5, 10 via Q470 chipset |
| Mounting |
Standard desktop or 4U rackmount configuration |
