| Processor |
|---|
| CPU | Intel® Core ™ 6th/7th/8th/9th i7 / i5 / i3 / Pentium / Celeron LGA1151 |
| Chipset | Intel® H110 |
| Memory architecture | Support DDR4 2400 |
| Memory capacity | up to 32GB |
| DIMM | 2×U-DIMM Slot |
| I/O Interface |
|---|
| LAN | 2×Intel GbE LAN controller |
| USB | 4×USB3.0, 4×USB2.0 |
| COM | 4×RS232, 2×RS232 or RS485 |
| Audio | Realtek ACL662 Audio controller Line-out Mic-in |
| LPT | 1 support SPP/EPP/ECP mode (Option) |
| PS2 | 1×PS2 Port (Keyboard & Mouse) |
| Display |
|---|
| VGA | Supports max resolution up to 1920x1200@60Hz |
| DVI | Supports DVI-D with max resolution up to 1920x1200@60Hz |
| Dual display | Supports asynchronous dual display |
| HDMI | Supports max resolution up to 4096x2160@30Hz |
| Physical |
|---|
| Dimensions | 370mm x 326.2mm x 187.2mm |
| Weight | 8.2KG |
| Box Structure | Hot dip galvanized sheet steel shell |
| Mounting |
|---|
| Mount | Desktop installation |
| Operating System |
|---|
| Microsoft Windows | Windows 7/10 |
| Linux | Ubuntu |
| Power |
|---|
| Power Adapter | AC180~264V |
| Power Dissipation | Depending on the CPU (select 300W, 400W, 500W, 600W, 750W) |
| Type | ATX |
| Environment |
|---|
| Work temperature | -20 ~ 60°C (-4℉~140℉) (Using Wide Temperature Grade Solid State Disk); 0 ~ 45°C (32℉~113℉) (Using normal temperature grade mechanical hard disk) |
| Storage Temperature | -40 ~ 80°C (-40℉~176℉) |
| Relative Humidity | 5~95% (Non condensation) |
| Vibration | SSD applied: 1.5 Grms IEC 60068-2-64 random 5 ~ 500 Hz 1 hr/axis |
| Shock | SSD applied: 10 G IEC 60068-2-64 Half-sine wave 11ms duration |
| EMC |
|---|
| EMC | CE/FCC Class B |
| Safety Certification |
|---|
| Safety Certification | CCC |
| Other |
|---|
| SSD | 1×2.5" HDD Bay, 1×3.5" HDD Bay |
| HDD | 1×full size mSATA SSD |
| WatchDog | 255 seconds programmable |
| Expansion Slot |
|---|
| PCIe | 1×PCIe x16 slot, 1×PCIe x4 slot, 1×PCIe x1 slot |
| PCI | 4×32bits PCI slots |
| Product Type |
Description |
| IPC-615G2-H110-P300 |
NO CPU/NO SODIMM/4*RS232/2*(RS232/485)/2×LAN/8×USB2.0 (Include 4xUSB3.0)/DVI/VGA/HDMI/4xPCI/3xPCI-E / Power 300W/AC IN 220V / Two-year warranty |
| IPC-615G2-H110-P400 |
NO CPU/NO SODIMM/4*RS232/2*(RS232/485)/2×LAN/8×USB2.0 (Include 4xUSB3.0)/DVI/VGA/HDMI/4xPCI/3xPCI-E / Power 400W/AC IN 220V / Two-year warranty |
| IPC-615G2-H110-P500 |
NO CPU/NO SODIMM/4*RS232/2*(RS232/485)/2×LAN/8×USB2.0 (Include 4xUSB3.0)/DVI/VGA/HDMI/4xPCI/3xPCI-E / Power 500W/AC IN 220V / Two-year warranty |
| IPC-615G2-H110-P600 |
NO CPU/NO SODIMM/4*RS232/2*(RS232/485)/2×LAN/8×USB2.0 (Include 4xUSB3.0)/DVI/VGA/HDMI/4xPCI/3xPCI-E / Power 600W/AC IN 220V / Two-year warranty |
| IPC-615G2-H110-P750 |
NO CPU/NO SODIMM/4*RS232/2*(RS232/485)/2×LAN/8×USB2.0 (Include 4xUSB3.0)/DVI/VGA/HDMI/4xPCI/3xPCI-E / Power 750W/AC IN 220V / Two-year warranty |
