TPC6000-C2384 | 23.8” Fanless Full HD Industrial Panel PC
23.8″ Full HD capacitive multi-touch fanless industrial Panel PC supporting Intel Core i3/i5/i7 CPUs
Features
- Intel® Core™ i7/i5/i3 CPU support (6th–9th Gen), LGA1151 up to 35W
- 23.8″ Full HD TFT LCD (1920 × 1080), 550 nits brightness
- Capacitive multi-touch panel with >87% light transmittance
- 3 x Intel GbE LAN (TPC6000-C2384-B-LP-P) or 5 x LAN (L5P version)
- 8 x DI (wet contact) and 8 x DO (PNP, 24V 500mA)
- 4 x RS232/RS485 serial ports with auto-flow control
- 1 x HDMI output, 4 x USB3.0, 2 x USB2.0, 1 x Mini-PCIe for 4G/Wi-Fi
- Fanless design with DC 12~24V input, panel/VESA mountable
- Wide temperature operation: 0~50°C, front panel IP65
- Supports Windows 7/8/10 and Linux
Multi-touch Panel PC Product Information
| Technical Specifications | ||
|---|---|---|
| Model Name | TPC6000-C2384-B-LP-P | TPC6000-C2384-B-L5P-P |
| System | ||
| CPU | Intel(r) CoreTM i7/i5/i3 6th/7th/8th/9th Gen, LGA1151, max 35W | |
| Chipset | Intel H510 | |
| Memory | 2 x DDR4 SO-DIMM, up to 32GB | |
| Storage | 1 x M.2 M-Key 2280 (PCIe Gen3 x4), 1 x mSATA | |
| I/O Interfaces | ||
| LAN | 3 x Intel Gigabit LAN | 5 x Intel Gigabit LAN |
| USB | 4 x USB3.0, 2 x USB2.0 | |
| Serial Ports | 4 x RS-232/RS-485 (auto flow control) | |
| Digital I/O | 8 x DI (wet contact, 24V), 8 x DO (PNP, 24V 500mA) | |
| HDMI | 1 x HDMI (1920×1080 @ 60Hz) | |
| Expansion | 1 x Mini-PCIe (supports Wi-Fi / 4G modules) | |
| Display | ||
| Screen Size | 23.8" TFT LCD | |
| Resolution | 1920 × 1080 | |
| Brightness | 550 cd/m² | |
| Contrast Ratio | 1000:1 | |
| Viewing Angle | 89° (L/R/T/B) | |
| Backlight Life | 30,000 hours | |
| Touchscreen | ||
| Touch Type | Capacitive Multi-Touch | |
| Transmittance | > 87% | |
| Touch Interface | USB | |
| Operating System | ||
| OS Support | Windows 7 / 8 / 10, Linux | |
| Power | ||
| Input Voltage | DC 12-24V ±10%, with protection | |
| Power Consumption | 35W (Idle) | |
| Mechanical | ||
| Mounting | Panel Mount / VESA Mount | |
| Dimensions (W × H × D) | 602.8 × 372.2 × 74 mm | |
| Cutout Size | 586 × 355 mm | |
| Weight | 7.9 kg | |
| Environmental | ||
| Operating Temperature | 0°C ~ 50°C | |
| Storage Temperature | -20°C ~ 60°C | |
| Humidity | 5% ~ 95% RH @ 40°C (non-condensing) | |
| Vibration | 1.5Grms, IEC60068-2-64 | |
| Shock | 10G, 11ms, IEC60068-2-27 | |
| EMC | CE / FCC Class B | |
| Waterproof | Front panel IP65 compliant | |
| Ordering Information | ||
|---|---|---|
| Part No. | Model | Description |
| A61.C2384.LP.0001 | TPC6000-C2384-B-LP-P | 23.8" 1920×1080 Panel PC, Intel Core i7/i5/i3 (6~9th Gen), 3 x Intel GbE, 4 x USB3.0, 2 x USB2.0, 4 x RS232/485, 8 x DI / 8 x DO, HDMI, Mini-PCIe, DC 12~24V, Panel/VESA mount |
| A61.C2384.L5P.0001 | TPC6000-C2384-B-L5P-P | Same as above but with 5 x Intel GbE LAN ports |
| Options | ||
| RAM | 4GB / 8GB / 16GB / 32GB DDR4 SO-DIMM | |
| M.2 SSD | 128GB / 256GB / 512GB / 1TB (PCIe Gen3 x4) | |
| mSATA SSD | 32GB / 64GB / 128GB / 256GB | |
| Wi-Fi Module | Mini-PCIe module with antenna | |
| 4G Module | Mini-PCIe EC20 or EC25 module with SIM slot and antenna | |
| Mounting Accessories | Optional panel mount clips and VESA bracket | |
| Power Adapter | Optional 60W AC to DC 12V/24V adapter with regional plug | |
