TPC6000-C124 | 12.1” Industrial Panel PC

12.1″ capacitive multi-touch industrial Panel PC support Intel Core i3/i5/i7 CPUs

Features

12.1″ industrial capacitive touch computer, XGA 1024×768 resolution
Supports 6th-9th Gen (LGA 1151) or 10th-11th Gen (LGA 1200) Core i3/i5/i7 CPUs, up to 65W
Available with 3 or 5 Intel 1000Mbps LAN ports
Includes 4 x RS232/RS485, 6 x USB (4 x USB3.0 + 2 x USB2.0)
Features 8 digital inputs (DI) & 8 digital outputs (DO) with NPN or PNP configurations.
Expandable with Mini-PCIe Slot – Supports WiFi, 4G LTE, and expansion modules
Rugged and active cooling design, durable aluminum chassis
Accepts DC12~24V ±10% with reverse polarity and overvoltage protection
Supports panel mounting & VESA mounting for easy integration
Dustproof & waterproof IP65-rated front panel

Multi-touch Panel PC Product Information

System
Model Name	TPC6000-C124-LH	TPC6000-C124-LH5	TPC6000-C124-B-LH	TPC6000-C124-B-LH5
CPU	Intel(r) CoreTM 6th/7th/8th/9th gen i7/i5/i3 LGA 1151		Intel(r) CoreTM 10th/11th gen i5/i3 LGA 1200
Chipset	H110		H510
Memory	2 x DDR4-2666/3200 MHz, Up to 32GB
Storage	1 x M.2 (M Key 2280 PCIe Gen3 x 4 Lane) 1 x mSATA
I/O
Network	3 x Intel 1000Mbps RJ-45	5 x Intel 1000Mbps RJ-45	3 x Intel 1000Mbps RJ-45	5 x Intel 1000Mbps RJ-45
USB	4 x USB3.0 + 2 x USB2.0
Serial Ports	4 x RS-232 / RS-485, RS485 supports automatic flow control
I/O Port	8DI+8DO (Wet contact input 24V, OC gate output 24V 500mA) with -P: 8DI (Wet contact input 24V), 8DO (PNP Output 24V 500mA)
HDMI	1920x1080 @ 60Hz
Expansion Slot	1 x Mini-PCIe slot, supports WiFi, 4G modules
Mechanical
Weight	3.7kg
Installation	Panel Mounted & VESA Mounted
Dimensions (W x H x D)	321mm x 247mm x 74mm
Cutout Size (W x H)	304mm x 230mm
OS Support
Operating Systems	Windows 7, Windows 8, Windows 10, Linux
Power
Voltage Input	DC12~24V ±10%, support reverse polarity protection, overvoltage protection, overcurrent protection
Idle Power Consumption	25W
LCD
LCD Size	12.1" XGA TFT
Resolution	1024 x 768
MTBF	50,000 hrs
Luminance	350cd/m²
Contrast Ratio	1000:1
Viewing Angle	(L) 80° / (R) 80° / (T) 60° / (B) 80°
Touchscreen
Type	projective capacitive touch screen
Transmittance	>87%
Controller Interface	USB
Environmental
Operating Temperature	0 ~ 50°C
Storage Temperature	-20 ~ 60°C
Relative Humidity	5~95% (40°C Non-condensing)
Vibration	SSD applied: 1.5 Grms, IEC 60068-2-64, random, 5 ~ 500 Hz, 1 hr/axis
Shock	Operating 10G peak acceleration (11ms duration), follow IEC 60068-2-27
EMC	CE/FCC Class B
Waterproof	Front IP65 compliant

Click the link below to download datasheets or drivers:

Datasheet Downloads

Driver Downloads

Ordering Information
Model Name	TPC6000-C124-LH	TPC6000-C124-LH5	TPC6000-C124-B-LH	TPC6000-C124-B-LH5	TPC6000-C124-LH-P / LH5-P / B-LH-P / B-LH5-P
Description	12.1" LCD, 1024x768, 4 x COM (RS232/485 Selectable), 3 x GLAN, 6 x USB, 8DIO, DC12~24V Input	12.1" LCD, 1024x768, 4 x COM (RS232/485 Selectable), 5 x GLAN, 6 x USB, 8DIO, DC12~24V Input	12.1" LCD, 1024x768, 4 x COM (RS232/485 Selectable), 3 x GLAN, 6 x USB, 8DIO, DC12~24V Input	12.1" LCD, 1024x768, 4 x COM (RS232/485 Selectable), 5 x GLAN, 6 x USB, 8DIO, DC12~24V Input	Same as non-P models, but with 8DO PNP Output instead of 8DO OC Gate Output
Options
CPU	Intel(r) CoreTM 6th/7th/8th/9th gen i7/i5/i3 LGA 1151 i3-6100, i3-7100, i3-8100, i5-6400, i5-6500, i5-6500T, i5-8400, i7-6700T, i7-8700		Intel(r) CoreTM 10th/11th gen i3/i5 LGA 1200 i5-10400T, i5-10500T, i5-11400T, i5-11500T, i5-11400, i5-11500, i5-10400, i5-10500		Same as respective models
Memory	DDR4 4GB, 8GB, 16GB
mSATA SSD	64GB, 128GB, 256GB, 512GB, 1TB
M.2 SATA SSD	128GB, 256GB, 512GB, 1TB, 2TB
WiFi Kit	miniPCIe WiFi Kit (7260 Series), Cylindrical Antenna
3G/4G Module	mini PCIe: EC20, EG25, EC25
Mounting Option	Panel Mounted & VESA Mounted
