| Technical Specifications |
|---|
| System |
|---|
| CPU | Intel(r) Apollo Lake J3355, Dual-Core 2.3GHz (TDP 10W) |
| Chipset | SoC integrated |
| BIOS | AMI EFI 16Mbit |
| Memory | 1 x SO-DIMM DDR3L 1666 MHz, up to 8GB |
| Display |
|---|
| Display Controller | Integrated graphics media accelerator |
| HDMI | Max resolution up to 4096×2160 @30Hz |
| I/O Interfaces |
|---|
| Serial Ports | 2 x RS232 (RS485 optional) |
| USB | 4 x USB3.0/2.0/1.1 |
| LAN | 2 x Intel i210 GbE (extendable up to 6 LAN ports) |
| Extended LAN | 4 x 1000Mbps RJ-45 (available on -L4 model) |
| Expansion |
|---|
| Mini PCIe | 2 x full-size Mini PCIe with SIM holder |
| Storage |
|---|
| Storage Medium | 1 x full-size mSATA SSD |
| Power |
|---|
| Input Voltage | DC 9-30V ±10% |
| Minimum Input | 12V, 3A |
| Power Consumption | 15W (no-load), 31W (full-load) |
| Power Adapter | Optional 12V/3.33A, 40W, Phoenix 2-pin terminal |
| Mechanical |
|---|
| Structure | Aluminum alloy box |
| Mounting | DIN-rail |
| Dimensions (L x W x H) | 145mm x 145mm x 75mm |
| Environmental |
|---|
| Operating Temperature | -20°C to 60°C (with wide-temp SSD), 0°C to 45°C (general HDD/SSD) |
| Storage Temperature | -40°C to 80°C |
| Humidity | 5-95% RH (non-condensing) |
| Vibration | 1.5 Grms (5-500 Hz, SSD, IEC 60068-2-64) |
| Shock | 10G (11ms, SSD, IEC 60068-2-64) |
| EMC | CE/FCC Class A |
| Safety Certification | CCC |
| OS Support |
|---|
| Operating System | Windows 10, Ubuntu |
| Ordering Information |
|---|
| Model Name | eBOX-3560 |
| Description | Fanless embedded box PC with Intel Apollo Lake J3355 CPU, 2 x RS232, 2 x LAN, HDMI, USB3.0, dual Mini PCIe, mSATA, DC9-30V input, DIN-rail mounting |
| Option Items |
|---|
| Memory | 4GB, 8GB DDR3L SO-DIMM |
| Storage | mSATA SSD (64GB, 128GB, 256GB) |
| 4G/WiFi Module | Mini PCIe module with SIM support (optional) |
| Power Adapter | 12V/3.33A (40W) with Phoenix 2-pin terminal plug |
| Mounting Kit | DIN-rail bracket (included) |
