| Technical Specifications — NP-61x2-L2 |
|---|
| Model Name | NP-6122-L2 | NP-6132-L2 | NP-6142-L2 |
| System |
|---|
| CPU | Intel® Core™ 6th/7th/8th Gen i7/i5/i3/Pentium/Celeron, LGA1151 | Intel® Core™ 10th/11th Gen i7/i5/i3, LGA1200 | Intel® Core™ 12th/13th/14th Gen i7/i5/i3, LGA1700 |
| CPU TDP | 65 W |
| BIOS | AMI UEFI BIOS |
| Memory | 2 × SO-DIMM DDR4-3200 MT/s, up to 32 GB | 2 × SO-DIMM DDR5-4800 MT/s, up to 64 GB |
| Storage | 1 × mSATA slot, SATA 3.0; 1 × M.2 2280 Key-B slot, SATA 3.0 |
| USB | 4 × USB 3.0; 1 × onboard USB 2.0 Type-A for dongle |
| COM | 2 × selectable RS-232/RS-485 (COM1–COM2), max. 115.2 kbit/s |
| Ethernet | 4 × Intel® i210-AT GbE LAN controllers |
| Remote switch | 1 × SW |
| DVI-D | Up to 1920 × 1080 at 60 Hz |
| HDMI | Up to 3840 × 2160 at 30 Hz |
| Watchdog timer | 1–255 programmable levels |
| TPM | fTPM |
| OS |
|---|
| Microsoft Windows | Windows 10; Windows 11 |
| Linux | Ubuntu; Debian; CentOS |
| Power |
|---|
| Voltage input | DC 12–24 V ±10%; overcurrent, overvoltage and reverse-polarity protection |
| Power consumption | Max. 120 W |
| Chassis |
|---|
| Construction / cooling | Aluminum-magnesium alloy enclosure with embedded fan-assisted cooling; wall or DIN-rail mounting |
| Dimensions (L × W × H) | 200 × 150.5 × 74.6 mm |
| Net weight | 2.2 kg |
| Environment |
|---|
| Operating temperature | −20 °C to +60 °C (−4 °F to +140 °F), with airflow and SSD |
| Storage temperature | −40 °C to +80 °C (−40 °F to +176 °F) |
| Relative humidity | 95% at 40 °C, non-condensing |
| Operating vibration | 5–500 Hz, 3 Grms, SSD and wall-mounted; IEC 60068-2-64 |
| Operating shock | 30 G peak acceleration, 11 ms, SSD and wall-mounted; IEC 60068-2-27 |
| EMC | CE EMC: EN 55032, EN 55035, EN IEC 61000-6-2, EN IEC 61000-6-4; FCC Class A |
| Safety | EN IEC 62368-1 |
Click the links below to search for datasheets or drivers:
| Ordering Information — NP-61x2-L2 |
|---|
| Part No. | Model | Description (unconfigured/base unit) |
|---|
| B73.61220.0E.0001 | NP-6122-L2 | CPU: NULL; RAM: NULL; mSATA: NULL; M.2: NULL; 2 × selectable RS-232/RS-485; 4 × GbE LAN; 4 × USB 3.0; HDMI/DVI-D; DC 12–24 V input |
| B73.61320.0E.0001 | NP-6132-L2 | CPU: NULL; RAM: NULL; mSATA: NULL; M.2: NULL; 2 × selectable RS-232/RS-485; 4 × GbE LAN; 4 × USB 3.0; HDMI/DVI-D; DC 12–24 V input |
| B73.61420.0E.0001 | NP-6142-L2 | CPU: NULL; RAM: NULL; mSATA: NULL; M.2: NULL; 2 × selectable RS-232/RS-485; 4 × GbE LAN; 4 × USB 3.0; HDMI/DVI-D; DC 12–24 V input |
| Options — NP-61x2-L2 |
|---|
| Item | NP-6122-L2 | NP-6132-L2 | NP-6142-L2 |
|---|
| CPU i3 | i3-6100, i3-6100T, i3-7100, i3-7100T, i3-8100, i3-8100T, i3-9100, i3-9100T | i3-10100, i3-10100T | i3-12100, i3-12100T, i3-13100, i3-13100T, i3-14100, i3-14100T |
| CPU i5 | i5-6500, i5-6500T, i5-7500, i5-7500T, i5-8500, i5-8500T, i5-9500 | i5-10500, i5-10500T, i5-11500, i5-11500T | i5-12500, i5-12500T, i5-13500, i5-13500T, i5-14500, i5-14500T |
| CPU i7 | i7-6700, i7-6700T, i7-7700, i7-7700T, i7-8700, i7-8700T, i7-9700, i7-9700T | i7-10700, i7-10700T, i7-11700, i7-11700T | i7-12700, i7-12700T, i7-13700, i7-13700T, i7-14700, i7-14700T |
| CPU i9 | i9-9900, i9-9900T | i9-10900, i9-10900T, i9-11900, i9-11900T | i9-12900, i9-12900T, i9-13900, i9-13900T, i9-14900, i9-14900T |
| CPU Other | G3900, G4400 | — |
| Memory | DDR4-3200: 4, 8 or 16 GB | DDR5-4800: 8, 16 or 32 GB |
| mSATA SSD | 64 GB, 128 GB, 256 GB, 512 GB, 1 TB |
| M.2 SSD | 128 GB, 256 GB, 512 GB, 1 TB, 2 TB |
| Mount option | DIN-rail |
| Parts Information — NP-61x2-L2 |
|---|
| Name | Part No. | Specification |
|---|
| 2-pin power supply terminal | JF7.000037.00.D03 | 5.08 mm, 1 × 2-pin wiring terminal |
| DIN-rail bracket | C78.570001.00.NDJ | DIN-rail bracket, IEC 60715, 35 mm wide, 1 mm thick |
| Wall-mount bracket | L21.000225.10.NKC | Hanging board |
Optional parts may require additional system certifications depending on the region. Contact NODKA for certificate compliance.
