TPC6000-C173-L Series | 17" Multi-Touch Industrial Panel PC

Rugged fanless Panel PC with Intel® J1900/J6412/N97/N305, dual GbE, 2×COM, 4×USB, VGA/DVI, DC12–24V, IP65 front; supports panel and VESA mounting

Features

17″ SXGA TFT with multipoint capacitive touch
Intel(r) J1900 / J6412 / N97 / Core i3-N305 CPU options
Fanless design with IP65-rated front panel
Dual 1000Mbps LAN, 4 × USB, 2 × COM (RS-232 with RS-485 optional)
VGA & DVI outputs; Line-out, PS/2 (Line-out not on J1900)
Wide 12-24V DC power input
Panel mount and VESA mount support
Mini-PCIe for 4G/Wi-Fi and EasyBUS slot for expansion

Multi-touch Panel PC Product Information

Technical Specifications -- TPC6000-C173-L
Model Name	TPC6000-C173-L-BTJ1900	TPC6000-C173-L-J6412	TPC6000-C173-L-N97	TPC6000-C173-L-N305
System
CPU	Intel(r) Celeron J1900 Quad-core 2.0GHz	Intel(r) Celeron J6412 Quad-core 2.0GHz	Intel(r) Processor N97 up to 3.6GHz	Intel(r) Core i3-N305 up to 3.8GHz
Memory	1 × DDR3L-1600, up to 8GB	1 × DDR4-2400, up to 16GB	1 × DDR5-4800, up to 16GB	1 × DDR5-4800, up to 16GB
Storage	1 × 2.5" SATA bay + 1 × mSATA
I/O Interfaces
USB	1 × USB3.0, 3 × USB2.0	2 × USB3.0, 2 × USB2.0	2 × USB3.0, 2 × USB2.0	2 × USB3.0, 2 × USB2.0
Serial Ports	2 × RS-232 (RS-485 optional) with surge protection
Ethernet	2 × Intel 1000Mbps RJ-45
Rear I/O	1 × DVI, 2 × GLAN, 4 × USB, 2 × COM, 1 × PS/2, 1 × Line-out (except J1900)
Expansion	1 × Mini-PCIe (4G/Wi-Fi), 1 × EasyBUS slot
OS Support	Windows 10, Linux
LCD
LCD Size	17" SXGA
Resolution	1280 × 1024
Luminance	250 cd/m²
MTBF	30,000 hrs
Contrast Ratio	1000 : 1
Viewing Angle (L/R/T/B)	85 / 85 / 80 / 80
Touch Screen
Type	Multipoint capacitive touch
Transmittance	≥ 87%
Controller Interface	USB
Power
Input Voltage	DC 12-24V
Maximum Power	< 60 W
Chassis
Structure	Ultra-compact fanless design; front panel IP65 compliant
Dimensions (W × H × D)	428 × 342 × 66 mm
Cut-out Size (W × H)	411 × 325 mm
Net Weight	5.54 kg
Environmental
Operating Temperature	0 ~ 50°C
Storage Temperature	-20 ~ 60°C
Relative Humidity	5 ~ 95% @ 40°C (non-condensing)
Vibration	SSD applied: 1.5 Grms, IEC 60068-2-64, random, 5-500Hz, 1 hr/axis
Shock	SSD applied: 10G, IEC 60068-2-27, half-sine, 11 ms
EMC	CE/FCC Class A

Click the link below to download datasheets or drivers:

Datasheet Downloads
Driver Downloads

Ordering Information -- TPC6000-C173-L
Model Name	Description
TPC6000-C173-L-BTJ1900	17" LCD / Intel J1900 2.0GHz / No Memory / No Hard / 2 × RS-232/485 (Optional) / 2 × LAN / 1 × USB3.0 / 3 × USB2.0 / 1280×1024 / DC12-24V input
TPC6000-C173-L-J6412	17" LCD / Intel J6412 2.0GHz / No Memory / No Hard / 2 × RS-232/485 (Optional) / 2 × LAN / 2 × USB3.0 / 2 × USB2.0 / 1280×1024 / DC12-24V input
TPC6000-C173-L-N97	17" LCD / Intel N97 / No Memory / No Hard / 2 × RS-232/485 (Optional) / 2 × LAN / 2 × USB3.0 / 2 × USB2.0 / 1280×1024 / DC12-24V input
TPC6000-C173-L-N305	17" LCD / Intel N305 / No Memory / No Hard / 2 × RS-232/485 (Optional) / 2 × LAN / 2 × USB3.0 / 2 × USB2.0 / 1280×1024 / DC12-24V input
Options
Expansion Card	4G/3G module (EC20, EC25, EG25...) -- Mini PCIe
DDR3L (J1900)	4GB, 8GB
DDR4 (J6412)	4GB, 8GB, 16GB
DDR5 (N97, N305)	8GB, 16GB
mSATA	128GB, 256GB, 512GB...
