Technical Specifications |
---|
Model Name | NP-6111-L2-J1900 | NP-6111-L2-E3845 | NP-6111-L2-J3455 | NP-6111-L2-J6412 |
System |
---|
CPU | Intel(r) Celeron J1900, 2.0GHz, 4 cores/4 threads, 2MB L2 cache | Intel(r) Atom E3845, 1.91GHz, 4 cores/4 threads, 2MB L2 cache | Intel(r) Celeron J3455, 1.5~2.3GHz, 4 cores/4 threads, 2MB L2 cache | Intel(r) Celeron J6412, 2.0~2.6GHz, 4 cores/4 threads, 1.5MB L2 cache |
TDP | 10W |
BIOS | AMI UEFI 64Mbit |
Memory | 1 x SO-DIMM DDR3L-1333MHz (max. 8GB) | 1 x SO-DIMM DDR4-2400MHz (max. 16GB) |
Storage | 1 x mSATA bay |
I/O Interfaces |
---|
USB | 1 x USB3.0, 3 x USB2.0 | 1 x USB3.0, 3 x USB2.0 | 2 x USB3.0, 2 x USB2.0 | 2 x USB3.0, 2 x USB2.0 |
Onboard USB | 1 x USB2.0 Type A for USB dongle |
Serial Ports | 2 x COM (RS232/RS485), RS485 supports auto flow control |
Ethernet | 4 x Intel GbE LAN controller |
Video Output | DVI-D (Supports up to 1920 x 1080 @60Hz) |
Watchdog Timer | 1~255 levels programmable |
Power |
---|
Voltage Input | DC12~24V ±10%, overcurrent, overvoltage, and polarity inverse protection |
Power Consumption | Max. 45W |
Chassis |
---|
Structure | Aluminum-magnesium alloy box, Fanless, Wall-mounted or DIN-Rail |
Dimensions | (L)200mm x (W)154.5mm x (H)74.6mm |
Net Weight | 1.8Kg |
Environmental |
---|
Operating Temperature | -20ºC ~ 60ºC (-4℉~140℉) with air flow (SSD) |
Storage Temperature | -40ºC ~ 80ºC (-40℉ ~ 176℉) with air flow (SSD) |
Relative Humidity | 5~95% (Non-condensing) |
Operating Vibration | 5~500Hz, 1.5Grms @with SSD, IEC60068-2-64 |
Operating Shock | 20G peak acceleration (11ms duration) with SSD, IEC60068-2-27 |
EMC | CE/FCC Class A |
