TPC6000-C1854-Ux | 18.5" HD/FHD Core Ultra Panel PC
18.5″ Panel PC with HD or Full HD capacitive display, Intel® Core™ Ultra 5/7, 3/5 Gigabit LAN, 4×COM, 8DI/8DO
Features
- 18.5″ capacitive touchscreen with 1366 x 768 or 1920 x 1080 resolution
- Intel® Core™ Ultra 5 125H / Core™ Ultra 7 255H
- Intel® Arc™ Graphics with Intel® AI Boost NPU
- Up to 96GB DDR5-5600 memory
- 3 or 5 x Intel Gigabit Ethernet
- 4 x RS-232 / RS-485 and 6 x USB
- Built-in 8DI + 8DO with optional PNP output configuration
- M.2 PCIe, mSATA and Mini-PCIe expansion
- DC12~24V industrial power input
- Panel Mount & VESA Mount with IP65 front panel
Multi-touch Panel PC Product Information
| Technical Specifications | ||||
|---|---|---|---|---|
| Model Name | TPC6000-C1854-Ux-L | TPC6000-C1854-Ux-L5 | TPC6000-C1854-Ux-LH | TPC6000-C1854-Ux-LH5 |
| System | ||||
| CPU | Intel® Core™ Ultra 5 Processor 125H / Intel® Core™ Ultra 7 Processor 255H, TDP 28W | |||
| GPU | Intel® Arc™ Graphics / Intel® Arc™ 140T GPU | |||
| NPU | Intel® AI Boost | |||
| Memory | 2 x DDR5 SO-DIMM slots, DDR5-5600MHz, up to 96GB | |||
| Storage | 1 x M.2 (M Key 2280 PCIe Gen3 x4) + 1 x mSATA | |||
| I/O Interfaces | ||||
| Network (LAN) | 3 x Intel 1000Mbps RJ-45 | 5 x Intel 1000Mbps RJ-45 | 3 x Intel 1000Mbps RJ-45 | 5 x Intel 1000Mbps RJ-45 |
| USB | 4 x USB3.0 + 2 x USB2.0 | |||
| Serial Ports | 4 x RS-232 / RS-485, RS-485 supports automatic flow control | |||
| I/O Port |
8DI+8DO Wet Contact Input (24V), OC Gate Output (24V 500mA)
With -P Models: 8DI Wet Contact Input (24V), 8DO PNP Output (24V 500mA) |
|||
| HDMI | 1 x HDMI, 1920x1080 @ 60Hz / 3840x2160 @ 30Hz | |||
| Expansion Slot | 1 x Mini-PCIe slot, supports WiFi and 4G modules | |||
| Mechanical | ||||
| Weight | 5.9kg | |||
| Installation | Panel Mount & VESA Mount | |||
| Dimensions (W x H x D) | 480mm x 304mm x 74mm | |||
| Cut-out Size (W x H) | 463mm x 287mm | |||
| Operating System Support | ||||
| OS | Windows 10, Windows 11, Linux | |||
| Power | ||||
| Input Voltage | DC12~24V ±10%, reverse polarity, overvoltage and overcurrent protection | |||
| Idle Power Consumption | 34W | 38W | ||
| LCD | ||||
| LCD Size | 18.5" TFT | |||
| Resolution | 1366 x 768 | 1920 x 1080 | ||
| MTBF | 30,000 hours | 50,000 hours | ||
| Brightness | 250cd/m² | 350cd/m² | ||
| Contrast Ratio | 1000:1 | |||
| Viewing Angle | (L) 89 / (R) 89 / (T) 89 / (B) 89 | |||
| Touch Screen | ||||
| Type | Capacitive Touch Screen | |||
| Transmittance | >87% | |||
| Controller Interface | USB | |||
| Environmental | ||||
| Operating Temperature | 0°C ~ 50°C | |||
| Storage Temperature | -20°C ~ 60°C | |||
| Relative Humidity | 5~95% @ 40°C, non-condensing | |||
| Vibration | 1.5Grms, IEC 60068-2-64, random, 5~500Hz, 1 hr/axis (SSD applied) | |||
| Shock | 10G peak acceleration, 11ms, IEC 60068-2-27 | |||
| EMC | CE/FCC Class B | |||
| Waterproof | Front IP65 Compliant | |||
| Ordering Information | ||||
|---|---|---|---|---|
| Model Name | TPC6000-C1854-U1-L | TPC6000-C1854-U1-L5 | TPC6000-C1854-U2-L | TPC6000-C1854-U2-L5 |
| Description |
18.5" LCD, 1366 x 768, 125H, 4 x COM (RS232/485 Selectable), 3 x GLAN, 6 x USB, 8DIO (DO NPN), DC12~24V Input
With -P Model: 8DIO (DO PNP) |
18.5" LCD, 1366 x 768, 125H, 4 x COM (RS232/485 Selectable), 5 x GLAN, 6 x USB, 8DIO (DO NPN), DC12~24V Input
With -P Model: 8DIO (DO PNP) |
18.5" LCD, 1366 x 768, 255H, 4 x COM (RS232/485 Selectable), 3 x GLAN, 6 x USB, 8DIO (DO NPN), DC12~24V Input
With -P Model: 8DIO (DO PNP) |
18.5" LCD, 1366 x 768, 255H, 4 x COM (RS232/485 Selectable), 5 x GLAN, 6 x USB, 8DIO (DO NPN), DC12~24V Input
With -P Model: 8DIO (DO PNP) |
| Model Name | TPC6000-C1854-U1-LH | TPC6000-C1854-U1-LH5 | TPC6000-C1854-U2-LH | TPC6000-C1854-U2-LH5 |
| Description |
18.5" LCD, 1920 x 1080, 125H, 4 x COM (RS232/485 Selectable), 3 x GLAN, 6 x USB, 8DIO (DO NPN), DC12~24V Input
With -P Model: 8DIO (DO PNP) |
18.5" LCD, 1920 x 1080, 125H, 4 x COM (RS232/485 Selectable), 5 x GLAN, 6 x USB, 8DIO (DO NPN), DC12~24V Input
With -P Model: 8DIO (DO PNP) |
18.5" LCD, 1920 x 1080, 255H, 4 x COM (RS232/485 Selectable), 3 x GLAN, 6 x USB, 8DIO (DO NPN), DC12~24V Input
With -P Model: 8DIO (DO PNP) |
18.5" LCD, 1920 x 1080, 255H, 4 x COM (RS232/485 Selectable), 5 x GLAN, 6 x USB, 8DIO (DO NPN), DC12~24V Input
With -P Model: 8DIO (DO PNP) |
| Options | ||||
| CPU |
Intel® Core™ Ultra 7 Processor 255H (16C16T, TDP 28W) Intel® Core™ Ultra 5 Processor 125H (14C18T, TDP 28W) |
|||
| Memory | DDR5 8G / 16G / 32G / 48G | |||
| Mini SATA SSD | 64G / 128G / 256G / 512G / 1TB | |||
| M.2 SSD | 128GB / 256GB / 512GB / 1TB / 2TB | |||
| WiFi | miniPCIe WiFi Kit (AX210 Series), Cylindrical Antenna | |||
| Expansion Slot | mini PCIe, EC20, EG25, EC25 | |||
