| Technical Specifications -- eBOX-3624-S |
| Model Name |
eBOX-3624-SE |
eBOX-3624-SP |
eBOX-3624-SN |
| System |
| CPU |
Intel® Core™ 6-9th i7 / i5 / i3 / Pentium / Celeron, LGA1151 (TDP 35W) |
| Chipset |
H110 |
| Memory |
1 x DDR4-2133/2400/2600MHz, MAX 32GB |
| Storage |
1 x 2.5 SATA, 1 x mSATA |
| USB |
4 x USB3.0 |
| COM |
COM1~COM2: RS232 |
| LAN |
2 x Realtek LAN |
| DVI |
The maximum resolution is 1920 x 1200@60Hz |
| VGA |
The maximum resolution is 1920 x 1200@60Hz |
| Extension Interface |
1 x Full-size MiniPCIe card slot with SIM card slot for expandable WIFI/4G |
| Transfer Specifications |
1 x PCI + 1 x PCIe x16 |
2 x PCI |
1 x PCIe x1 + 1 x PCIe x16 |
| Watch Dogs |
1~255 levels programmable setting |
| OS Support |
| OS |
Windows 10, Windows 11, Linux |
| Power |
| Input Voltage |
DC 12V input with overcurrent, overvoltage, and anti-reverse protection |
| Chassis |
| Dimensions |
(L)323mm x (W)251.9mm x (H)88.9mm |
| Net Weight |
3.7Kg |
| Environment |
| Work Temperature |
-20ºC ~ 60ºC (Use SSD) |
| Storage Temperature |
-40ºC ~ 80ºC (Use SSD) |
| Relative Humidity |
5~95% RH@40°C, non-condensing |
| Vibration |
SSD applied: 1.5Grms, IEC 60068-2-64, random, 5~500Hz, 1 hr/axis |
| Shock |
SSD applied: 10G, IEC 60068-2-27, Half sine wave, lasting 11ms |
| EMC |
CE/FCC Class A |
| Ordering Information |
|---|
| Model | CPU | Description |
| eBOX-3000H | Intel(r) CoreTM i7/i5/i3, Pentium, Celeron (6th-9th Gen) | Fanless embedded PC with 6 x COM, 2 x LAN, 8 x USB, triple display (VGA, DVI, HDMI), dual Mini PCIe, PCIe x16 or dual PCI, mSATA + 2.5" HDD, 12-24V input |
| Optional Items |
|---|
| Memory | 4GB / 8GB / 16GB / 32GB DDR4 SO-DIMM |
| Storage | mSATA SSD (64GB-512GB), 2.5" SATA HDD/SSD |
| Expansion | PCIe x16 or 2 x PCI (selectable), 2 x Mini PCIe with SIM support |
| Wireless Module | Mini PCIe Wi-Fi/3G/4G module with SIM card slot |
| Power Adapter | 12-24V AC/DC adapter with Phoenix connector (optional) |
| Mounting Kit | Wall-mount bracket (included) |
