eBOX-3240-R2 | Fanless Box PC with 8 COM, Triple Display
Intel J6412-powered fanless box PC with 8 serial ports, triple display, M.2 5G support, dual storage, and wide temperature support
- Fanless Industrial Box PC with aluminum-magnesium alloy housing
- Intel® Celeron J6412 quad-core processor (2.0GHz, 1.5MB cache)
- 8 x COM ports: COM1–4 and COM7–8 (RS232/RS485), COM5–6 (RS232)
- 2 x Gigabit LAN ports for reliable network connectivity
- Triple display output: HDMI, DisplayPort, and VGA
- 6 x USB ports: 3 x USB 3.0, 3 x USB 2.0
- M.2 slot for 5G module with USB extensible protocol
- Dual storage: 1 x 2.5” SATA + 1 x M.2 SATA SSD
- 12V DC input with overcurrent, overvoltage, and reverse polarity protection
- Wall-mountable, compact design suitable for control cabinets
- Operating temperature: -20°C to 60°C (with airflow & SSD)
Fanless Industrial Box PC Product Information
| Technical Specifications | |
|---|---|
| System | |
| Model Name | eBOX-3240-R2 |
| CPU | Intel(r) Celeron J6412, 2.0GHz, 1.5MB Cache |
| Memory | 2 x DDR4L 2666/2933/3200MHz SO-DIMM, up to 32GB |
| Storage | 1 x 2.5" SATA, 1 x M.2 Key-M Slot (SATA SSD, 2242/2280) |
| I/O Interfaces | |
| USB | 3 x USB 3.0, 3 x USB 2.0 |
| COM Ports | COM1~COM4: RS232/RS485 COM5~COM6: RS232 COM7~COM8: RS232/RS485 |
| LAN | 2 x Realtek GbE Ethernet |
| Display | |
| HDMI | 4096 x 2160 @30Hz |
| DP | 4096 x 2160 @30Hz |
| VGA | 1920 x 1200 @60Hz |
| Expansion | |
| M.2 Slot | 1 x M.2 slot for 5G module with extensible USB protocol |
| Power | |
| Input Voltage | DC 12V ±10% with overcurrent, overvoltage, and reverse polarity protection |
| Power Consumption | Typical: 10-15W |
| Mechanical | |
| Structure | Aluminum-magnesium alloy box, Fanless, Wall-mounted |
| Dimensions | 234mm (L) x 150mm (W) x 60mm (H) |
| Net Weight | 1.9Kg |
| Environmental | |
| Operating Temperature | -20°C ~ 60°C (with airflow, mSATA) |
| Storage Temperature | -40°C ~ 80°C (with airflow, mSATA) |
| Humidity | 5-95% RH (non-condensing) |
| Vibration | 5-500Hz, 1.5Grms (with SSD, IEC 60068-2-64) |
| Shock | 10G peak acceleration, 11ms (with SSD, IEC 60068-2-27) |
| EMC | CE/FCC Class B |
| OS Support | |
| Microsoft Windows | Windows 10 IoT |
| Linux | Ubuntu |
Click the link below to download datasheets or drivers:
| Ordering Information | ||
|---|---|---|
| Model | CPU | Description |
| eBOX-3240-R2 | Intel(r) Celeron J6412 | Fanless box PC with 8 x COM, 2 x LAN, 6 x USB, triple display (HDMI + DP + VGA), SATA + M.2 SSD, M.2 for 5G, 12V DC input, wall-mount chassis |
| Optional Items | |
|---|---|
| Memory | 4GB / 8GB / 16GB / 32GB DDR4L SO-DIMM |
| Storage | 2.5" SATA SSD/HDD, M.2 SATA SSD (2242/2280) |
| Wireless Module | M.2 5G module with USB protocol; Mini PCIe 4G/Wi-Fi with SIM (optional) |
| Power Adapter | 12V/5A AC/DC adapter with Phoenix connector (optional) |
| Mounting Kit | Wall-mount bracket (included) |
